Product model:ZLG1F02L

Charge and discharge port:Same port

Board size:136*80*20mm

Passive balance:<100mA

Supported string number:8-17S

Sleep power consumption:<100uA

Discharge working current:80A (adjustable)

Optional communication methods:Bluetooth, 4G communication, isolation line

Temperature detection:4 channels

Application scenarios:Low-speed electric vehicles, electric motorcycles, AGVs, robots, energy storage

Product model:BMS801L

Charge and discharge port:Same port

Board size:144*50*12mm

Passive balance:<100mA

Supported string number:3-5S

Sleep power consumption:<100uA

Discharge working current:100A (adjustable)

Optional communication mode:Isolated RS485, Uart

Temperature detection:4 channels

Application scenario:12V small energy storage, 12V lead to lithium power supply, special power supply

Product model:BMS1F01L

Charge and discharge port:Same port

Board size:156*75*18mm

Passive balance:<100mA

Supported string number:8-16S

Sleep power consumption:<100uA

Discharge working current:120A (adjustable)

Optional communication method:Isolation RS485/CAN, Bluetooth

Temperature detection:4 channels

Application scenarios:Low-speed electric vehicles, power-assisted vehicles, electric motorcycles, communication vehicles

Product model:ZLG801L

Charge and discharge port:Same port

Board size:145*75*16mm

Passive balance:<100mA

Supported string number:8-16S

Sleep power consumption:<100uA

Discharge working current:80A (adjustable)

Optional communication mode:Isolated RS485/CAN, Bluetooth, 4G communication

Temperature detection:4 channels

Application scenarios:Low-speed electric vehicles, electric motorcycles, AGVs, robots, rental battery replacement
