BMS1F01H

* Support host computer, Bluetooth applet, APP detection data;

* It has multiple software protection functions such as over voltage, over current, over discharge, over temperature, anti-reverse connection and short circuit

* Built-in high-precision SOC algorithm, accurately and effectively detect the real state of the battery

* Software parameters can be customized,Supports ternary, lithium iron phosphate, sodium-ion, and others

National Service Hotline
400-0755-166
Parameter
Product ModelBMS1F01H
Cell Series Supported17-24S
Product Size200*85mm*25mm
Discharge Current150A(可调)
Temperature Protection6路
Communication隔离RS485/CAN、蓝牙Bluetoot
Charge/Discharge Port同口/Same Port
Balance Current50-100MA
Sleep Mode50-100uA
Low-voltage Switch
